Wellhead Tools and Accessories
Standard Certified · Modular Design · Reliable & Durable
- Standardization & Certification: Certified to ISO standards.
- Modular Design: Enables quick installation and reduces on-site operational risks.
- Corrosion-Resistant Materials: Ceramic coatings, 316SS, etc., suitable for high-sulfur environments.
- Engineering Experience: Widely applied in domestic high-pressure gas fields and complex working condition projects.
Onshore Completion Equipment
Casing Heads/Casing Spools
- Models: C-22, C-29 (light/heavy load), Slip-Type Casing Heads
- Features: Compliant with API 6A standards; straight-through design avoids wear and supports BOP testing; slip-type requires no welding for quick installation (30 minutes).
Casing Hangers
- Models: C-21 (light load), C-22 (medium load), C-29 (heavy load)
- Features: Slip self-energized sealing; temperature resistance from -46°C to 121°C; compatible with API casing sizes; high reliability of H-type seal boxes.
Tubing Heads & Tubing Hangers
Tubing Heads
- Models: Single String (TCM), Dual String (TC-60)
- Features: Single String (TCM): Compatible with TC-1A-FN hangers; side outlets support production pipeline connection.
Dual String (TC-60): Segmented suspension design, suitable for high-pressure dual-string completions.
Tubing Hangers
- Models: Elastomer-Sealed TC-1A-FN, Metal-Sealed (M2M)
- Features: Elastomer-Sealed TC-1A-FN: Optional downhole safety valve control lines.
Metal-Sealed (M2M): Suitable for high-pressure (15,000 psi / 103.5 MPa) and corrosive environments.
Wellhead Valves & Control Equipment
Gate Valves (HGS/HSC Series)
Full-bore design; metal sealing; resistant to H₂S/CO₂; working pressure range of 2,000~15,000 psi.
Surface Safety Valves (SSV)
Automatic shutdown under pressure loss/overpressure; fire protection; shutdown time < 5 seconds; compliant with API 6A PSL3G.
Control Panels
Single-well/multi-well control: Integrates hydraulic/pneumatic logic; supports remote ESD (Emergency Shutdown) and fire alarm cutoff.
Fracturing & Testing Equipment
Fracturing Trees
20,000 psi working pressure; acid-resistant; modular design for quick connection.
Surface Test Trees
Supports test strings; emergency well shutdown; pressure resistance of 15,000 psi.
Fracturing Manifolds
Multi-channel diversion; wear-resistant ceramic throttle valves; suitable for continuous multi-well fracturing.
Special Application Devices
Plunger Wellhead Blowout Prevention System
Automatic liquid drainage; extends gas well lifespan; no external power required.
Precision Pressure Control Devices
Intelligently adjusts throttle valves; real-time data feedback; suitable for sulfur-containing working conditions.
